Car battery charging devices supply direct current (DC) to recharge batteries and restore spent electrolyte. These systems not only enhance safety and introduce new features but also reduce the risk of battery failure, ensuring a reliable power supply for all vehicle components. It is essential for these components to function properly, and automotive battery charging systems must withstand harsh environments, including extreme temperatures, humidity, rain, acid smoke, vibrations, electromagnetic interference (EMI), and current surges.
When designing a car battery charging PCB (Printed Circuit Board), several factors must be considered, including inductor orientation, lead coupling, grounding vias, and fill areas. The orientation of inductors should allow for maximum spacing, and they should be arranged at right angles. Comprehensive grounding should be placed beneath leads, and the through holes in sensitive areas should accommodate inductance modules. Additionally, continuous ground impedance should be maintained in terms of grounding and filling, with the filling line terminals grounded using an array of through holes.
Car Battery Charging PCB Assembly
The Kingsheng PCBA battery charger PCB features high transmission power, a wide operational range, low loss, and stable performance. The car battery charging PCB we designed has successfully passed various quality tests, including load output, no-load output, full-load efficiency, short circuit protection, and circuit protection.
Car battery charging PCB assembly performance parameters:
Number of layers: 1, 2, 4 to 6 layers, up to 18 layers
Solder mask color: white black yellow green red
Copy Punching: Routing, V-CUT, Chamfering
Board cutting: Shear, V-score, Tab-routed
Minimum Drilling Diameter: 0.01", 0.25mm, or 10mils
Copper Weight Tolerance: +/-0.25 oz
Plate Thickness Tolerance: +/-10%
Copper Thickness: 3 oz
Substrate: FR4, CEM3, FR1, Taconic, Rogers
Why Choose China PCBA Supplier KSPCBA as Your Car Battery Charging PCB Assembly Manufacturer?
– Experienced and skilled team
– State-of-the-art equipment
– Strict quality control
– Excellent customer service
– Competitive price
Please send Email to kspcba@c-alley.com or call us through +86 13828766801 Or submit your inquiry by online form. Please fill out below form and attach your manufacturing files( PCB Gerber files and BOM List) if need quotation. We will contact you shortly.
