PCB Board Debugging Method

When dealing with a new PCB board, the first step is to check for any physical issues such as cracks, short circuits, or open circuits. It is also important to verify if the resistance between the power supply and the ground wire is adequate. For new circuit boards, debugging can be challenging, especially with larger boards and numerous components. However, having a systematic approach to debugging can make the process more effective.

PCB Board Debugging Steps:

1) Begin by checking the board for any visible problems, and then proceed to install the components. It's advisable to install modules independently to easily identify any faults and prevent time wastage. When installing the power supply part, ensure that the output voltage is normal. Consider using an adjustable regulated power supply with current limits for safety.

2) Gradually install other modules and test each one individually. Be cautious during the power-up process to avoid overcurrent and component damage due to design or installation errors.

Detection Methods For PCB Board

How to Identify PCB Board Failures:

1) Voltage Measurement Method: Start by checking the power supply pins of each chip to confirm their voltage. Additionally, verify the normalcy of various reference voltages and working voltages at different points. Abnormal voltages may indicate a fault.

2) Signal Injection Method: Inject a signal into the input terminal and measure the waveform at each point to identify any abnormalities. Simple methods such as touching the input terminals can also help detect faults.

3) Other Methods: Visual inspection for physical damages, listening for abnormal sounds, detecting unusual smells, and testing for abnormal temperatures can also help identify faults in PCB boards. Experienced electronic maintenance personnel are often sensitive to these signs.

By following these steps and methods, debugging and identifying faults in PCB boards can be carried out more effectively.
