How to Design a Better PCB

Home | Events | PCBA | About Us | News | Contact Us

The proper design of a printed circuit board (PCB) is crucial for the success of a project. It's essential to have the right materials and expertise from the beginning. PCB fabrication and manufacturing start with the right design. Many PCBs fail due to cheap engineering or lack of specialized knowledge and experience.

Understanding PCB design basics is important to avoid extensive revisions that can delay the project and increase costs. Working with engineering experts from the start allows for designing for manufacturability and ensures a cost-effective, efficient final product.

How to make your PCB design better

(1) Create a schematic

Many engineers prioritize layout work, but the schematic diagram is essential for generating a netlist for PCB inspection. The schematic is crucial for circuit debugging and communication. Making annotations in the schematic diagram helps mark potential issues in the circuit layout, providing useful reminders. Using a hierarchical schematic diagram reduces workload and risk by compartmentalizing circuits into different modules. Designing based on a mature design is less risky than creating a new circuit.

(2) Optimize circuit layout

A good PCB layout simplifies wire drawing and enhances PCB performance. Aligning the PCB layout with the signal path ensures smooth signal transmission. Dividing the board into areas based on functional modules and separating analog and power signals helps optimize the layout. Attention to detail such as device placement, signal shielding, and optimization can save time during the wire drawing process.

(3) Establish design rules

Setting wiring rules in PCB design software helps prevent negligence and mistakes. Detailed rule setting can help avoid low-level errors and regulate the design process. Automated routing functions in EDA tools can assist in design, provided that the rules are set in enough detail.
