To standardize the PCB process design of a product, the relevant parameters of the PCB process design are specified. This ensures that the PCB design meets the technical specification requirements of manufacturability, testability, safety regulations, EMC, EMI, etc. The process of building the product during the product design process is focused on technology, quality, and cost advantages. The scope of application specification applies to the PCB process design of all electronic products and is used in activities such as PCB design, PCB board process review, single board process review, and others.

What is SMT processing?

SMT processing refers to the electronic client providing materials to the electronic processing party for PCB processing and production due to insufficient equipment and technical experience. This service is required by most electronic developers as it saves a significant amount of capital investment and factory rent, thereby reducing production costs and increasing the added value of products.

PCB design specifications and SMT processing

SMT Processing Flow

Quality is always the ultimate requirement for all electronic product processing, including SMT processing. Here's a detailed introduction to the process:

1. The two parties conduct detailed negotiations on the processing project and sign a cooperation contract once they confirm the details.

2. The client submits PCB documents, BOM, and component materials. The PCB documents and BOM are used to confirm the accuracy of the component mounting direction and materials.

3. Incoming material inspection and processing. IQC testing of materials is carried out to ensure production quality. Some components need to be processed, such as material trimming and component forming.

4. On-line production. The first piece will be proofed before going online, and mass production will be carried out after both parties confirm its accuracy. This involves stencil production, solder paste printing, PCB component placement, reflow process, and red glue process.

Why Choose China PCBA Supplier KSPCBA as Your PCB design specifications and SMT processing Manufacturer?

– Experienced and skilled team

– State-of-the-art equipment

– Strict quality control

– Excellent customer service

– Competitive price
