Printed Circuit Boards (PCBs) are an important component of electronic products. They play a vital role in implementing the functionality of electronic products, making PCB design crucial. The performance of PCB design directly affects the function and cost of electronic products. A well-designed PCB can ensure that electronic products are manufactured smoothly and meet all demands of practical application.

Among all the elements that contribute to PCB design, Design for Manufacture (DFM) is essential. It links PCB design and manufacturing, allowing problems to be identified early on during the whole life cycle of electronic products. It has been thought that PCB design complexity increases as electronic products' manufacturability is taken into consideration during the PCB design phase. However, DFM can make electronic products easily get involved in automatic manufacturing and save labor costs during the manufacturing process, while effectively shortening the production time to ensure timely delivery of the final electronic products.

PCBA Manufacturability Design

It is crucial to optimize the surface assembly and crimping components to ensure high efficiency and quality of assembly. The process path should be designed to be as short as possible, with a focus on single-sided or double-sided reflow welding. The layout of components must be scientific and reasonable to reduce bad solder joints and tooling usage. Coordinating the design of pads, solder masks, and stencil openings can greatly improve the straight-through rate of welding.

When introducing new packages, it is important to carry out a small batch of process verification. BGAs, chip capacitors, and crystal oscillators should be placed in areas where PCBs are prone to bending and deformation during welding, assembly, workshop turnover, transportation, and use. It is essential to continuously optimize and improve design rules based on emerging poor assembly or failure cases.
