Many electronic product companies are interested in finding a professional supplier who can produce their products from start to finish. However, if it is the first time taking the entire PCBA outsourcing model, misunderstandings can occur. To avoid this, the editor of KSPCBA will analyze the whole process of PCBA processing in detail with you.

1. Business communication: The process starts with a business negotiation stage, just like the previous half-package mode of SMT patch and PCB proofing separately. Both parties need to carry out a business communication stage in the early stages to ensure that the customer's requirements are understood and that the PCBA processing factory can deliver the desired outcome.

2. Evaluation of the Quotation: The PCBA processing factory will evaluate and provide a quotation based on the customer's BOM list and Gerber data. This step helps evaluate the product's cost, and both parties can proceed to the next step after confirming the quotation.

3. Customer places an order: The customer needs to determine the number of stocks required, and how many orders will be placed with the PCBA manufacturer. The SMT placement factory will analyze and evaluate the customer's product delivery according to its own schedule and production capacity to determine whether it can complete the order delivery task within the time specified. After this, both parties can accept the delivery date, or it can be confirmed in the form of a contract after coordination.

Process of PCBA Processing

4. Procurement of components: As a one-stop service for PCBA, a factory is necessary to purchase electronic components. After the contract is signed, the PCBA processing plant will purchase materials according to the customer's BOM list.

5. Incoming inspection: Inspecting and sealing the purchased materials is a routine operation as only products that pass the quality inspection can be used in production. Another special use of sealed samples is to facilitate customers to re-inspect the materials purchased by suppliers.

6. PCBA manufacturing stage: This stage is the link with the most process and process control in field operations. It includes solder paste mixing, solder paste printing, SPI solder paste inspection, SMT patch processing, reflow oven temperature curve setting, AOI full inspection, DIP plug-in wave soldering, etc.

7. PCBA test: Testing is a link that must be carried out after PCBA manufacturing is completed, including programming, burn-in, functional testing, and so on. Only after passing the test link designated by the customer's product, can the product with the PASS seal enter the packaging link.

8. Packing and transportation: After completing the PCBA manufacturing test, the packaging can be carried out after reaching the customer's standard and approval. There are general packaging and anti-static packaging. This needs to be evaluated according to the customer's product characteristics, and then the logistics link can be used.

After sorting out the above 8 links, we can see which links we need to coordinate with the company and suppliers and proceed with the selection of PCBA suppliers after fully understanding them. Of course, different companies may have different operating methods.
