10 items you need to receive fast and accurate flex PCB quotes.

These items apply to printed circuit board, flex circuit assembly, and flex PCB quotes.

Electronic CAD files in RS-274X extended Gerber format

Mechanical drawing with tolerances

Stack-up drawing

Technical specifications (if different than IPC-6012 or IPC-601)

Array drawing or maximum array size (if part is to be provided as a multiple up panel)

Application conditions and special requirements

Expected lead-time or expected delivery date

Bill of Material (if component assembly required)

Reliability test requirements

Electrical and/or functional test requirements

Don’t start your new project on the wrong foot, supply as many of these items as possible.

A PCB Assembly service provider will present a client with a PCB Assembly quotation, which is an estimate of the cost to assemble electrical components onto a printed circuit board (PCB). It is an important step in the PCB assembly process since it allows customers to plan their production and get a ballpark estimate of the cost of their project.

Details like the cost per unit, material cost, turnaround time, and any additional fees or prices for services like component sourcing, PCB testing, or conformal coating are usually included in the quotation for PCB assembly. The pricing is determined by the specific PCB design criteria, component requirements, and PCB quantities provided by the customer.
