Advantages of THT PCB assembly:

Improved mechanical connections: Through-hole components are perfect for applications involving mechanical stress since their leads go through the PCB's holes to form stronger linkages.

Soldering ease: Because through-hole soldering is simpler, novices and do-it-yourselfers can benefit from it.

Replacing components: Because of their greater size and soldering technique, through-hole components are more accessible and therefore easier to replace.

Increased capacity for power handling Higher power and voltage levels can be handled by through-hole components than by surface-mount components.

Disadvantages of THT PCB assembly:

PCB size increase: Because through-hole components take up more room on the PCB, it is more challenging to create compact designs.

Slower assembly: When assembling through-hole components by hand, it takes longer than when assembling surface-mount components automatically.

Costlier: The bigger PCB size and longer assembly times may result in more expensive manufacturing.

Advantages :

Thru-hole soldering provides stronger mechanical bonds than any other technique.

Thru-hole soldering is the optimal technique for connectors, transformers, electrolytic capacitors, and other heftier circuit board components.

Thru-hole soldering is considered to be the go-to process over SMT for many military or aerospace products.

Disadvantages :

Thru-hole soldering requires drilling into the bare board, which makes it a more time consuming process than SMT.

Thru-hole soldering is more expensive than using SMT.

Thru-hole mounting may not allow for as high a component density as SMT does.

Thru-hole mounting often requires hand-soldering, which is considered to be less reliable than the reflow ovens used in surface mount PCBA.

In summary, compared to SMT PCB assembly, THT PCB assembly has a number of drawbacks. It's a less ideal solution in many applications because of the limited component density, the human assembling process, and the increased danger of component damage. THT PCB assembly is still utilized, although, in some applications—such as high-power applications or applications needing extremely dependable components—where SMT is not appropriate.
