Three Ways to Order PCB Assembly

About Us | Events | Company Structure | Management Staff Structure | Market Focus | Company Certification | Our Services

To create PCBs, the printed circuit board business requires a Gerber file. The required PCB data is frequently created using this file type. It is the designer's responsibility to guarantee that the data they produce is accurate and comprehensible to both the manufacturer and the designer. PCB manufacturers now offer additional services in addition to PCB manufacturing. Certain manufacturers have mastered the art of component procurement and PCB assembly with the use of robotic systems that align components precisely. Some manufacturers have found success with these additional services. A PCB maker offers a range of services that customers can select from.

We typically don't need to speak with the manufacturer again once we have completed the circuit board's initial design and performed a preliminary check to make sure it complies with design guidelines. We can contact the manufacturer for a fresh pricing quote after the circuit board is designed, or we can examine the previous one. Our top engineers and the payment department will be instructed to proceed with the payment if we approve of the price.

A price quote can be automatically calculated for us by several producers using web technologies. We need to notify them of our location and upload our circuit board files. Subsequently, the gadget will compute the total cost by factoring in setup expenses, the cost of every circuit board, packaging, shipping, and any other relevant charges.

Turnkey: We source all components required

Consigned: You send all components to us

Combo: You send some of the components and we source the rest

PCB Assembly capabilities include both surface mount technology (SMT) and thru-hole manual assembly. We use the latest YAMAHA Pick & Place equipment, Glenbrook Technologies precision X- Ray imaging, and YESTech Optical Inspection units. To view a complete list of our PCB assembly equipment, click here.

Our quickturn prototype assembly service supports fine pitch components as small as 15 mil pitch, passive components as small as 0201 package, and ball grid arrays (BGA) as small as .4mm pitch with X-Ray inspected placements. Solder types include leaded and lead-free RoHS compliant and we use laser-cut stainless-steel stencils (nano-coating available).

For more information about our full service PCB manufacturing capabilities and our in-house prototype PCB assembly services, please contact us.
