Eight Key Phases to the PCB Engineering Cycle

About Us | Events | Company Structure | Management Staff Structure | Market Focus | Company Certification | Our Services

To guarantee the performance of the final product, the printed circuit board (PCB) manufacturing process necessitates a complicated method. Despite the fact that circuit boards might be single, double, or multilayered, the manufacturing techniques employed only change once the initial layer is produced. Some PCBs may need to go through 20 or more phases in the manufacturing process due to variations in their construction.

The complexity of printed circuit boards is correlated with the number of stages involved in their production. Any step skipped or the process shortened could have a detrimental effect on the circuit board's functionality. Nevertheless, the PCBs should function correctly as essential electronic components after they are finished.

The Engineering Development Cycle

1 – Quote Phase

2 – Definition Phase

3 – Electrical/Mechanical Design Phase

4 – Printed Circuit Board Design & Fab Phase

5 – PCB Assembly Phase

6 – Integration & Test Phase

7 – Functional Test Procedure Phase

8 – Functional Testing Phase

The difficulties encountered by PCB fabrication are not recent. But given the intricacy of today's manufacturing techniques and goods, they can have even bigger effects and scale. That emphasizes how urgently change is needed right now.

Customer demand volatility is an inevitable byproduct of our growing demand for more energy-efficient gadgets as well as our growing influence in the high-tech sector. Modern "core" items sometimes have much more versions and shorter life cycles in addition to their complexity. For manufacturers to achieve all of this, their operational flexibility must be increased step-by-step.

The majority of volatility stems from a distribution system in which demand lurches have been propagated from consumers and commercial clients all the way to the manufacturing floor by the removal of buffer stockpiles. Reengineering the entire manufacturing process is necessary to ensure that it can respond quickly and effectively to changes in product mixes and schedules brought on by instability in the end market.
